Hustler Raptor XDX 60″ Zero-Turn Mower

$1,400.00 OFF

Hustler Raptor XDX 60″ Zero-Turn Mower

$13,299.00$1,400.00 OFF

As comfortable being used by the astute acreage owner or the lawn mowing contractor, the Raptor XDX is the perfect entry level professional machine at a home user price.

Buy Now, Pay Later

Up to $2,000 with Humm

Click here to apply now

Interest-Free Finance

Up to $50,000 with Humm90

Click here to apply now

The NEW Raptor XDX combines the best features of the commercial grade Fastrak into the body of a Raptor, giving you the best of both worlds at a price that won't break the bank. With a deep 5" cutting deck, commercial grade spindles, and big commercial Hydrogear 3100 hydrostatic drives, this machine is just as much at home on the trailer of the landscape contractor as it is in the astute home owners garage.

  • Commercial grade 10ga. welded steel deck w' leading edge deck reinforcement w' Commercial duty sealed deck spindles.
  • Fabricated one piece chassis. Not bolt together! Toughest frame, front forks, and deck in class.
  • Reliable industry leading Kawasaki FR Series V-Twin FR730V engine.
  • SmoothTrak steering with a patented automatic park brake system.
  • Premium Twin Hydro Gear ZT3100 integrated serviceable commercial duty hydro's.
  • Superior Bolstered extra High-Back seat with armrests and built in lumbar support.
  • Hustler Exclusive 22" BigBite drive tyres and 13" caster tyres.
  • 12.5 km p/h forward ground speed.
  • Beautiful quality of cut. Your lawn will be the envy of the neighbourhood.
  • Flip up floor pan and removeable seat pan plus Tool-less removable pulley covers for easy maintenance.
  • Domestic Warranty : 3 Year or 400 hour Domestic Warranty

  • Commercial Warranty : 3 Year or 400 hour Commercial Warranty

  • Engine (cc) : 726 cc

  • Engine : Kawasaki FR730V

  • Horsepower : 24.0hp (Please Note: Horsepower rating as tested to SAE J1995 Standards.)

  • Fuel Capacity : 11.4 L

  • Blade Length : 52cm x 3 Blades

  • Dry Weight : 323 kg

  • Fuel : Unleaded fuel - maximum of 10% ethanol in fuel (see engine manufacturers specifications)

  • Drive System : Dual hydrostatic. Commercial-duty Hydro-Gear ZT3100

  • Ground Speed - Forward : Infinitely variable 0-12.5 km/h

  • Ground Speed - Reverse : 0-8 km/h

  • Brakes : In Service: Hydrostatic dynamic braking. Parking: Internal transmission mechanical brake. When steering levers are placed in neutral position, integral park brakes are automatically engaged

  • Caster Tyres : 13 x 6.5, smooth tread

  • Tyres - Drive : Exclusive 22 x 11 - 10 BigBite tyre

  • Seat : Superior Bolstered extra High-Back seat with armrests and built in lumbar support.

  • Hour Meter : Standard

  • ROPS : No ROPS

  • Seat Suspension : Spring suspension

  • Height : 111cm

  • Width : 158cm (with discharge chute raised)

  • Width (tyre-to-tyre) : 123cm

  • Deck System : Side-Discharge: 60" cut. Free-floating deck using three blades with centre blade to the front. Deck is suspended at the corners. Includes 3 deck-mounted rollers to improve flotation in rolling and uneven terrain.

  • Cutting Widths : 60” (1524 mm) cut side discharge

  • Deck Lift : Foot-operated deck height adjustment in 6 mm increments from 38.1 mm to 114.3 mm.

  • Deck Construction : 10 ga, .135” (3.4 mm) welded steel with 11 ga, .120" (3.0 mm) doubler welded onto spindle mount areas. Solid 11ga. steel bars reinforce impact areas on trim edges. Commercial-style box-section reinforced front edge.

  • Cutting Height(s) : Magnetic Pin for setting cut height

  • Blade(s) : (3) Heavy-duty, heat treated, blades. 16.50" x 2.50" x .20"

  • Blade Tip Speed : 18,400 fpm

  • Discharge Chute : High density, rubberised.

  • Transmission : Hydro-Gear ZT3100

  • Kit - Mulch : Not Standard - Available Option

  • Grass Catcher : Not Standard - Accessory Available

  • Length : 181cm
