The SupaSwift 30-Ton log splitter provides quality and power at an affordable price. Fitted with a SupaSwift (9.5 hp, 270 cc) engine, an auto return valve with an 12.9 second cycle time and quality features throughout this log splitter will provide many years of reliable service.
-
Domestic Warranty: 3 Year Domestic Warranty
-
Commercial Warranty: 3 Month Commercial Warranty
-
Hire/Rental Warranty: 3 Month Hire/Rental Warranty
-
Engine: SupaSwift, 9.5 hp 270cc, horizontal shaft, single cylinder OHV engine.
-
Hydraulic Ram Cylinder: (mm): Outside: 139.7 mm x 609.6 mm stroke / Inside: 127mm x 622.3 mm stroke
-
Hydraulic Tank Capacity: (L): 50 litres [Hydraulic system including hydraulic tank]
-
Maximum Log Length: (mm): 25″ / 635 mm
-
Pump: (L): Two stage pump 17.1 GPM (77.73 litres per minute)
-
Tow Hitch: (mm): *2″ (50 mm) ball hitch with safety chains – Aust style trailer bail hitch
-
Wedge: (mm): 9″ (228.6 mm) High angled heat treated steel
-
Operating Position: Horizontal or vertical operation
-
Capacity: 30 Tons of splitting force
-
Valve: Auto return valve with adjustable detent
-
Cycle Time: 12.9 seconds (down and back)
-
Wheels / Tyres: *D.O.T approved 12″ x 4.80″ multi lug trailer wheel
-
Beam (mm): 9″ Foot plate / 228.6 mm Foot plate
-
Ram Size: 2″ (50.8 mm) Dia
